Carburettor Puch Maxi

• Carburetor
• Bing Replica
• Model with elbow / Horizontal banjo
• 12MM
• Manifold connection 20MM
• Filter / suction rubber connection 20MM
• Comes with nozzle without imprint
• We always recommend ordering a nozzle set to get the best adjustment
• Note, use 4MM Replica jets


• Carburettors should always be cleaned before mounting

  Fits on:
• Zundapp
• Puch Maxi

• Bing Carburetor
• 15MM
• Type 1/15/46
• Original Bing carburetor
• Puch Maxi
• Zundapp


• Connection diameter manifold: 20MM
• Connection diameter airfilter: 20MM

• Carburetor
• Bing Replica 15MM
• Comes with jet without print, size 70
• Note, use 3.5MM jets
• Manifold connection 20MM
• Connection filter / suction rubber 20MM
• Carburettors should always be cleaned before mounting


• Note, on this model, the choke must be pulled back up manually. If desired, order a separate choke slide, see related parts

  Suitable for:
• Puch Maxi
• Zundapp

Bend Bing carburettor. ( 6MM )
Fits;

• Bing 12MM Puch Maxi / Zundapp
• Bing 15MM Puch Maxi / Zundapp
• Bing 17MM Puch Monza
• Bing 17MM Kreidler

• Cable adjustment screw ( 5MM )
• The screw in the elbow

  Fits;
• Bing 12MM Puch Maxi / Zundapp
• Bing 15MM Puch Maxi / Zundapp
• Bing 17MM Puch Monza
• Bing 17MM Kreidler

• Throttle drum cover
  Fits on;
• Bing 12MM Puch Maxi / Zundapp
• Bing 15MM Puch Maxi / Zundapp

• Throttle drum cover gasket
  Fits on;
• Bing 12MM Puch Maxi / Zundapp
• Bing 15MM Puch Maxi / Zundapp


• See images for sizes



• Throttle drum cover spring
• Bing

  Fitting for:
• Bing 12MM Puch Maxi / Zundapp
• Bing 15MM Puch Maxi / Zundapp


• See images for sizes



• Spring plate throttle slide Bing
  For;
• Bing 12MM Puch Maxi / Zundapp
• Bing 15MM Puch Maxi / Zundapp
• Bing 17MM Puch Monza
• Bing 17MM Kreidler

• Throttle needle clip

  For;
• Bing 12MM Puch Maxi / Zundapp
• Bing 15MM Puch Maxi / Zundapp
• Bing 17MM Puch Monza
• Bing 17MM Kreidler
• Bing 17MM Zundapp

• Throttle drum Bing
• Bing 12MM Puch Maxi / Zundapp
• Bing 15MM Puch Maxi / Zundapp

• Banjo bolt
• Bing
• 12-15MM

• Banjo
• Bing 12-15MM
• Angled connection

• Fiber gasket Bing
• For Banjo bolt or Hose nozzle

  Fits;
• Bing 12MM Puch Maxi / Zundapp
• Bing 15MM Puch Maxi / Zundapp
• Bing 17MM Puch Monza
• Bing 17MM Kreidler
• Bing 10MM Kreidler 1-10-77

• Choke slide Bing
• Bing 12MM Puch Maxi / Zundapp
• Bing 15MM Puch Maxi / Zundapp

• Spring for Carburettor lid
• Bing 12-15-17MM

• Choke pin
• Fits on Bing carburetors 12 > 15 MM

• Bolt throttle cover

  For;
• Bing 12MM Puch Maxi / Zundapp
• Bing 15MM Puch Maxi / Zundapp
• Bing 17MM Puch Monza
• Bing 17MM Zundapp
• Bing 17MM Kreidler
• Bing 10MM Kreidler 1-10-77

• Hex bolt
• M6 X 20
• Galvanized
• Full thread
• Din 933

M6 Washer
Galvanized
Din 125A

• Manifold 15MM
• Usable for Bing 12 & 15mm carburetors
• Connection diameter 20MM
  Suitable for;
• Puch Maxi


• See image for sizes

• Intake gasket
• To use for standard & 15mm carburettor
• Puch Maxi

• Floater needle

  Fits:
• Bing 12MM Puch Maxi / Zundapp
• Bing 15MM Puch Maxi / Zundapp
• Bing 17MM Puch Monza
• Bing 17MM Kreidler
• Bing 10MM Kreidler 1-10-77


  And for Bing Type 17 and 18, Squared Carburettors:
• 18/12/112 ( Puch )
• 17/10/103 ( Zundapp )


• See extra images



• Floater pin
  For;
• Bing 12MM Puch Maxi / Zundapp
• Bing 15MM Puch Maxi / Zundapp
• Bing 17MM Puch Monza
• Bing 17MM Kreidler
• Bing 10MM Kreidler 1-10-77

Floater.
Fits;

• Bing 12MM Puch Maxi / Zundapp
• Bing 15MM Puch Maxi / Zundapp
• Bing 17MM Puch Monza
• Bing 17MM Kreidler

• Floatertank
  For;
• Bing 12MM Puch Maxi / Zundapp
• Bing 15MM Puch Maxi / Zundapp
• Bing 17MM Puch Monza
• Bing 17MM Kreidler
• Bing 10MM Kreidler 1-10-77

• Floater gasket
  Fits;
• Bing 12MM Puch Maxi / Zundapp
• Bing 15MM Puch Maxi / Zundapp
• Bing 17MM Puch Monza
• Bing 17MM Kreidler
• Bing 10MM Kreidler 1-10-77

• Needle Jet
• Bing Replica
• Fitting for a Bing Replica nozzles

  For;
• Bing 12MM Puch / Zundapp
• Bing 15MM Puch / Zundapp
• Bing 17MM Puch Monza
• Bing 17MM Kreidler

• Clamp bolt
• For Bing 12 & 15MM Carburetors

• Idle adjusting screw
• For Bing 10-12-15MM Carburetor

• Spring idle adjusting screw


• Bing 12MM Puch Maxi / Zundapp
• Bing 15MM Puch Maxi / Zundapp
• Bing 10MM Kreidler 1-10-77
