Rear Wheel hub Zundapp 517

• Spoke
• A piece
• Chrome
• 181MM for small hub
• Zundapp

• Wheel hub
• To use for the Front & Rearside
• Zundapp 120MM
• "Small Hub"
• Including bearings

• Bearing SKF
• 6201 2RS
• Inner diameter 12MM
• Outer diameter 32MM
• Width 10MM

  Is used for:
• Kreidler front wheel Left + Right
• Kreidler rear wheel Left + Right
• Zundapp 3 Gears. Front + Rear wheels (spoked)
• Zundapp Sprinter Front + Rear wheels (12 spoke cast wheels)
• Enfield Explorer
• Kreidler Flory MF23
• Wheel bearing Tomos A35

• Circlip
• Zundapp 517
• Front & Rear Hub ( 120MM - Small model )


• See extra images

• Rebuild kit Ø 120MM hub
• 4 Pieces

  Set contains:
• 2x 6201 2RS bearings
• 1x Spacer
• 1x Circlip

  Fits on:
• Zundapp 510 (Model 1962)
• Zundapp 515
• Zundapp 517
• Zundapp 529

• Sprocket carrier / Hub flange
• Small hub 120MM

  Fits on:
• Zundapp 517
• Zundapp 529



• Sprocket rubber
• Good fit!
• Fits on a Zundapp Old model
• Small rubbers
• Sizes; 11X19.4X12MM


• Note, these go per piece!

• Bearing SKF
• 6203 2RS
• Inner diameter 17MM
• Outer diameter 40MM
• Width 12MM
  Is used for:
• Zundapp sprocket carrier

• Cover plate set for sprocket carrier
• 3-Pieces

  Set contains:
• 1x Cap (433-15.121)
• 1x Felt ring (433-15.119)
• 1x Cover plate (433-15.117)

  Fits a.o:
• Zundapp 517
• Zundapp 529
• Zundapp 530

Rear sprocket

• Zundapp.
• 43 Teeth.
• Stitch 3/16 (Normal)
• Use a 415 Chain.

Rear sprocket

• Zundapp.
• 41 Teeth.
• Stitch 3/16 (Normal)
• Use a 415 Chain.

M8 Spring washer Flat
Galvanized
Din 127

• M8 Spring washer
• Stainless Steel
• Din 127B

• M8 Nut
• Stainless Steel
• Din 934

• Nut M8
• Galvanized
• Din 934

• Hollow axle
• Including nut
• Old type


• Zundapp 517



• Spacer Rear wheel
• Left
• Zundapp


• See images for sizes



Chain tensioner Left

• Zundapp 517

Identical to zundapp article number
Z433-15.632

• Chain tensioner Stainless Steel
• Left
• Zundapp 517

• Chain tensioner Stainless Steel
• Zundapp 517
• Zundapp 529/530
• Right

Chain tensioner Zundapp.

Model: Round hole Right

Identical to zundapp article number
Z529-15.711

Hollow axle nut

• Zundapp

Washer Brake key.

• Zundapp

Identical to Zundapp article number
Z267-05.597

O-Ring.

• Zundapp Brake key
• See extra image

• Brake lever
• Rearside
• Short model
• Zundapp 517


• Nut
• Brake key Zundapp all models
• M8 - Low nut
• A Piece
• See extra image

Brake shoes

• Zundapp
• For small hub (120MM)
• Both front and rear

• Spacer Rear wheel Right
• Galvanized
• Zundapp

• Spacer Rear wheel Right
• From Stainless Steel
• Zundapp 517
• Zundapp 529/530
• Both big & small hub

• Rear wheel axle
• Zundapp
• Key width 14MM
• 12MM
• Length 164MM

Cable adjustment screw.

• M6 X 35.
• universally applicable
• Zundapp Clutch Cable

Identical to Zundapp article number
Z515-17.715

M6 Nut
Stainless Steel.
Din 934

• Spoke nipple Zundapp / Kreidler
• A piece


• See images for sizes
