Exploded views Kreidler

Technical drawings, manuals and "exploded views" for Kreidler
A lot of work is still being done on old Kreidler mopeds in workshops throughout the country. Enthusiastic hobbyists keep the legacy of this famous German brand alive by keeping models like the Florett, the TM, LF, RM and of course the RS on the road.

Maintaining Kreidler knowledge
To prevent the technical knowledge for maintaining these legendary mopeds from disappearing, we have a complete range of technical information available for our customers. This technical information consists of technical drawings of, for example, the engine block of the Kreidler 5 Gears, direct gear. Exploded views are also available for the engine part of the Florett and a complete user manual for the Kreidler MP9.

Order online
Technical information such as manuals or a partscatalog are crucial for every fan of Kreidler mopeds. At JMPB Parts we are working to keep expanding our database with this information. In addition, all parts for Kreidler mopeds can be ordered online 24/7 via our webshop. Everything at competitive prices and delivered quickly! This way we help to maintain Kreidler as a moped brand in the street scene.

Order via our drawings
We have worked out the drawings of some types so that you can immediately order the appropriate parts.
To order with the help of the drawings, see the link below:

Go to Parts by drawing
