Front Cast Wheel Puch Monza

• Brake caliper
• Complete with brake pads

  Fits on;
• Puch Monza
• Puch Cobra
• Puch Maxi EBR Hydraulic Front Fork


• See images for sizes

Brake pads.

• Puch Monza
• Puch Cobra




M6 Washer
Galvanized
Din 125A

M8 Washer
Galvanized
Din 125A

Hexagon bolt M6X40
Galvanized
Part thread
Din 931

Hexagon bolt

• M8 X 40
• Din 931
• Part thread
• Galvanized

• Split pin
• 3X32MM
• Galvanized
• Din 94




• Brake caliper rebuild kit
• Zundapp
• 30X12MM
• For an original brake caliper

• Nut M8
• Galvanized
• Din 934

• Nut M6
• Galvanized
• Din 934

Copper ring 10X14MM
Thickness 1,5MM
Din 7603A

• Banjo bolt brake
• M10X1
• A.o. AJP
• Total length below the head 21MM

Hex bolt M8 X 16
Galvanized
Full thread
Din 933

Lock washer

• M8
• Stainless Steel
• DIN 6798A

• Front wheel axle
• Puch Monza
• M12

• Speedometer driver
• Puch Monza

Circlip Axle.
Size; 17MM.
Din 471

• Bearing SKF
• 6003 2RS
• Both sides sealed
• Inner diameter 17MM
• Outer diameter 35MM
• Width 10MM

Hex bolt M6 X 30
Galvanized
Full thread
Din 933

Shimring 18X25X0.5.
DIN988

Shimring 18X25X0.3.
DIN988

Brake disc Stainless Steel.

• Puch Monza Grand Prix.
• Inner diameter: 39MM

• Outer diameter: 219MM

• Diameter boreholes: 6MM

• Holes center distance: 48MM

M6 Locknut
Galvanized
Din 985

• Rim tape
  To be used for;
• 16 Inch rims
• 17 Inch rims

• Inner Tube
• Size: 2.25 / 2.50 X 17
• Straight valve
• Michelin Airstop

• Tire
• Line profile band
• Brand; Kenda
• Type K202
• Size; 2.50 X 17
• Load index 38 (132KG / 291LBS)
• Speed index P (150KM / 93MPH)
• Tube Type (For use with inner tube)

• Tire
• Semislick / Street profile
• Brand; Metzeler
• Type ME22
• Size; 2.50 X 17
• Load index 43 (155KG / 342LBS)
• Speed index P (150KM / 93MPH)
• Tube Type (For use with inner tube)

• Tire
• Street profile / All weather
• Brand; Deestone
• Type D967
• Size; 2.50 X 17
• Load index 38 (132 KG / 58 LBS)
• Speed index L (120 KM / 75 MPH)
• Tube Type (For use with inner tube)
