Exploded view drawings front wheel l Yamaha DT50MX

Grouped product items
Product Name	Qty
3 - Ring for Spacer Wheel Yamaha DT50MX/RD50M Ring for spacer Front & rearwheel Yamaha DT50MX Yamaha RD50M €2.75	Out of stock
4 - Bearing 6301 2RS SKF Bearing SKF 6301 2RS Inner diameter 12MM Outer diameter 37MM Width 12MM Is used for example; Zundapp Wheels front and Rear ( Alu Rims) €7.95
5 - Seal Front Wheel Yamaha DT50MX Right Seal Frontwheel Right side Yamaha DT50MX Size; 18X37X8 €2.89
7 - Brake Shoes FS1 Original Brake shoe set . Yamaha FS1. Original Yamaha product. €19.50
7 - Brake Shoes FS1/DT/RD/TY With Springs Set Brake shoes, front or rear. Fits on; Yamaha FS1 Yamaha DT Yamaha RD Yamaha TY Including springs. €6.95	Out of stock
10 - Bushing for speedometer Worm Yamaha FS1/DT Bushing For Speedometer Worm Yamaha FS1 Yamaha DT See extra image ( Nr 10 ) €4.95
12 - Seal Speedometer Worm Yamaha FS1/DT Seal Speedometer Worm Yamaha FS1 Yamaha DT50M Yamaha DT50MX €2.15
13 - Ring for Speedometer axle Yamaha FS1/DT Ring for Speedometer axle Yamaha FS1 Yamaha DT50M €2.50
14 - Filler Speedometer driver Yamaha FS1/DT Filler ring Speedometer driver A piece Yamaha FS Yamaha DT50M Yamaha DT50E €2.45
15 - Driver plate Speedometer Yamaha FS1/DT Driver plate for Speedometer Yamaha FS1 Yamaha DT50 Yamaha DT50M €3.90
16 - Circlip mounting Speedometer Worm Yamaha FS1/DT Remake Circlip mounting Speedometer Worm A Piece Remake Yamaha FS1 Yamaha DT50M Yamaha DT50E €0.25
17 - Brake lever set Front Yamaha DT50/80MX Brake lever set 4-pieces Front wheel Fitting for: Yamaha DT50MX Yamaha DT80MX €16.95
20 - Brake key Yamaha 14MM FS1/DT Brake key 14MM ( Note, this can vary per type Yamaha ) Yamaha FS1 2RU Front & Rear Yamaha DT50M Front & Rear Yamaha DT50E Front & Rear Yamaha DT50MX Front & Rear €33.95
22 - Seal Front wheel Yamaha FS1/DT Left Seal Front wheel Left Yamaha FS1 Yamaha DT50 Yamaha DT50M €12.50
23 - Spoke set Front Wheel Yamaha DT50MX Spoke set Front wheel ( 21 Inch ) Yamaha DT50MX Length 241MM & 227MM 36 Pieces Nipples included €29.95
24 - Rim B-choice Chrome 1.60 X 21 Rim Chromed B-choice, Chrome is not too thick, so there are sanding traces Size; 1.60X21 A: 59MM B: 41MM C: 24MM Diameter spoke hole: 7MM 36 holes €29.95
25 - Dust cover Front wheel Right Yamaha FS1 Dust cover Front wheel Right Yamaha FS1 €8.95
25 - Dust cover Front wheel Right Yamaha FS1 Remake Dust cover Front wheel Remake Right Yamaha FS1 €4.95
26 - Front wheel axle Yamaha DT50/80MX Complete Front wheel axle Complete 12X220MM With Castle nut and Split pin Fittinf for: Yamaha DT50MX Yamaha DT80MX €8.95
27 - Castle Nut M12 Yamaha Castle Nut Yamaha M12 €4.50
28 - Split pin 2X25 Galvanized Din 94 Split pin 2X25 Galvanized Din 94 €0.30
28 - Clip speedometer cable Yamaha FS1/DT Original Clip For mounting the speedometer cable Yamaha FS1 Yamaha DT50MX Original €2.95
28 - Clip speedometer cable Yamaha FS1/DT Clip For mounting the speedometer cable Yamaha FS1 Yamaha DT50MX €0.85
31 - O-Ring Speedometer Cable Yamaha FS1/DT O-Ring For Speedometer Cable Yamaha FS1 Yamaha DT50MX €0.99
33 - Inner Tube 2.50/2.75 X 21 Kenda Inner tube Kenda Straight valve For sizes: 2.50 X 21 2.75 X 21 €9.50
34 - Rim tape 21 Inch Rim tape22MM For 21 inch rims €3.50
35 - Repair set front wheel hub Yamaha DT50/80MX Repair set For the front wheel hub Contains: 2 X Front wheel bearings Front wheel seal Front wheel cup Front wheel bushing Spacers Fits on: Yamaha DT50MX Yamah DT80MX See extra image €22.95
36 - Kilometer Wormset Yamaha DT50/80MX Kilometer Worm Set 8 Pieces Contains: Gear Counter worm Bus with seal Circlips Filler rings Fitting for: Yamaha DT50MX Yamaha DT80MX €29.95
